Phoenix / Salad UI - Basics

Exploring Salad UI in a Phoenix App

Bill Tihen
Last updated on Thu, 31 Oct 2024 Code, Elixir Language, Phoenix Framework, Frontend

Overview

We recently build an app and quickly realized the usefulness of a UI Framework. We chose Salad UI because it is based on Tailwind the now default CSS system in Phoenix. We also like the idea that it creates components that are consistent with Phoenix’s architecture.

Getting Started

Let’s get the newest erlang, elixir and phoenix.

# macos 15 seems to need this
ulimit -n 10240

# install the newest erlang found at: https://www.erlang.org/downloads
asdf install erlang 27.1
asdf global erlang 27.1

# install the newest elixir (with a matching erlang release) https://github.com/elixir-lang/elixir/releases
asdf install elixir 1.17.3-otp-27
asdf global elixir 1.17.3-otp-27

# install the newest phoenix
elixir -v
mix local.hex
mix archive.install hex phx_new # 1.7.14

# create a new phoenix project
mix phx.new salad_ui

cd salad_ui
mix ecto.create

# run phoenix
iex -S mix phx.server

Install Salad UI

Salad UI Demo & Docs, however, I find the SaladUI Hex Docs or its Repo better for installation instructions.

  1. Install salad_ui hex package:
  • Add salad_ui in mix.exs:
def deps do
  [
    ...,
    {:salad_ui, "~> 0.4.2"}
  ]
end
  • run: mix deps.get
  1. Now go to: https://ui.shadcn.com/themes
  • click the customize button
  • after choosing a theme click the copy code button.
  • paste this code into the file: assets/css/app.css- I chose to use:
// assets/css/app.css
@layer base {
  :root {
    --background: 0 0% 100%;
    --foreground: 224 71.4% 4.1%;
    --card: 0 0% 100%;
    --card-foreground: 224 71.4% 4.1%;
    --popover: 0 0% 100%;
    --popover-foreground: 224 71.4% 4.1%;
    --primary: 262.1 83.3% 57.8%;
    --primary-foreground: 210 20% 98%;
    --secondary: 220 14.3% 95.9%;
    --secondary-foreground: 220.9 39.3% 11%;
    --muted: 220 14.3% 95.9%;
    --muted-foreground: 220 8.9% 46.1%;
    --accent: 220 14.3% 95.9%;
    --accent-foreground: 220.9 39.3% 11%;
    --destructive: 0 84.2% 60.2%;
    --destructive-foreground: 210 20% 98%;
    --border: 220 13% 91%;
    --input: 220 13% 91%;
    --ring: 262.1 83.3% 57.8%;
    --radius: 0.5rem;
    --chart-1: 12 76% 61%;
    --chart-2: 173 58% 39%;
    --chart-3: 197 37% 24%;
    --chart-4: 43 74% 66%;
    --chart-5: 27 87% 67%;
  }

  .dark {
    --background: 224 71.4% 4.1%;
    --foreground: 210 20% 98%;
    --card: 224 71.4% 4.1%;
    --card-foreground: 210 20% 98%;
    --popover: 224 71.4% 4.1%;
    --popover-foreground: 210 20% 98%;
    --primary: 263.4 70% 50.4%;
    --primary-foreground: 210 20% 98%;
    --secondary: 215 27.9% 16.9%;
    --secondary-foreground: 210 20% 98%;
    --muted: 215 27.9% 16.9%;
    --muted-foreground: 217.9 10.6% 64.9%;
    --accent: 215 27.9% 16.9%;
    --accent-foreground: 210 20% 98%;
    --destructive: 0 62.8% 30.6%;
    --destructive-foreground: 210 20% 98%;
    --border: 215 27.9% 16.9%;
    --input: 215 27.9% 16.9%;
    --ring: 263.4 70% 50.4%;
    --chart-1: 220 70% 50%;
    --chart-2: 160 60% 45%;
    --chart-3: 30 80% 55%;
    --chart-4: 280 65% 60%;
    --chart-5: 340 75% 55%;
  }
}
  1. Create the file: assets/tailwind.colors.json and paste the following into:
{
  "accent": {
    "DEFAULT": "hsl(var(--accent))",
    "foreground": "hsl(var(--accent-foreground))"
  },
  "background": "hsl(var(--background))",
  "border": "hsl(var(--border))",
  "card": {
    "DEFAULT": "hsl(var(--card))",
    "foreground": "hsl(var(--card-foreground))"
  },
  "destructive": {
    "DEFAULT": "hsl(var(--destructive))",
    "foreground": "hsl(var(--destructive-foreground))"
  },
  "foreground": "hsl(var(--foreground))",
  "input": "hsl(var(--input))",
  "muted": {
    "DEFAULT": "hsl(var(--muted))",
    "foreground": "hsl(var(--muted-foreground))"
  },
  "popover": {
    "DEFAULT": "hsl(var(--popover))",
    "foreground": "hsl(var(--popover-foreground))"
  },
  "primary": {
    "DEFAULT": "hsl(var(--primary))",
    "foreground": "hsl(var(--primary-foreground))"
  },
  "ring": "hsl(var(--ring))",
  "secondary": {
    "DEFAULT": "hsl(var(--secondary))",
    "foreground": "hsl(var(--secondary-foreground))"
  }
}

Ideally copy this from the docs in case of updates.

  1. Now in assets/tailwind.config.js add the following into the correct parts of this file:
module.exports = {
  content: [
      "../deps/salad_ui/lib/**/*.ex",
    ],
  theme: {
    extend: {
      colors: require("./tailwind.colors.json"),
    },
  },
  plugins: [
    require("@tailwindcss/typography"),
    require("tailwindcss-animate"),
    ...
  ]
}

be sure tailwind-animate is installed:

cd assets
npm i -D tailwindcss-animate
# or yarn
yarn add -D tailwindcss-animate
  1. Add the colors file to config/config.exs
config :tails, colors_file: Path.join(File.cwd!(), "assets/tailwind.colors.json")
  1. add the following to assets/js/app.js
window.addEventListener("phx:js-exec", ({ detail }) => {
  document.querySelectorAll(detail.to).forEach((el) => {
    liveSocket.execJS(el, el.getAttribute(detail.attr));
  });
});

you can close an opening sheet like this.

  @impl true
  def handle_event("update", params, socket) do
    # your logic
    {:noreply, push_event(socket, "js-exec", %{to: "#my-sheet", attr: "phx-hide-sheet"})}
  end

We will demonstrate this in the code samples.

  1. SKIP! To make dark and light mode work correctly, add following to assets/css/app.css
body {
  @apply bg-background text-foreground;
}
  1. If borders don’t work properly add @apply border-border !important; to assets/css/app.css
@layer base {
  @apply border-border !important;
  :root {
    ...
  }
}

Add login

mix phx.gen.auth Accounts User users --web Auth
mix deps.get
mix ecto.migrate

now you should see register and login links in the top right.
